Dual Mast Mobile Aluminium Work Platform

Product / Stacker

Dual Mast Mobile Aluminium Work Platform

Model Number : VI-AWP-M-10 (II) AC, VI-AWP-M-12 (II) AC

HSN Code : 84289090

Stock: In-Stock

Main Specs : Push Around / Pulling Device, Outrigger Sensors, platform extension, Solid tyres as standard

Equipment Details

VIMAL mobile dual mast aluminium work platforms are widely used to for the installation and maintenance of the narrow spaces such as hotels, modern workshops, business halls, lobbies, railway stations etc. Low energy consumption, no pollution, no damage to the grounds. Mainly to be used for indoor maintenance, repair work User can control the lifting operation directly from the platform. The aerial work platform mast structure is made with aluminium material.

VIMAL reach stacker is suitable for various conditions use. Our reach stacker can be a good replacement for forklift. Equipped with good sight mast and ergonomic design control system, enhance the working efficiency and reduce operator’s fatigue. Streamlined appearance, compact design, brings comfort to its users. Small turning radius and advacned electronic controller system enhance the stability of the vehicles.

TECHNICAL SPECIFICATIONS

Model		VI-AWP-M-10 (II)	VI-AWP-M-12 (II)
Lift Capacity	kg	200	200
Platform Occupancy Max	m	1	1
Working Heigth Max	m	12	14
Platform Height Max	m	10	12
Stowed Length	m	1.76	1.76
Stowed Width	m	1	1
Stowed Height	m	2	2
Platforn Size	m	1.52*0.62	1.52*0.62
Outrigger Footprint	m	2.1*2.00	2.1*2.00
Ground Clearance	m	0.05	0.05
Lifting Motor (AC)	kw	1.1	1.1
Weight (AC)	kg	780	830
Optional Power Source	V/Ah	24/100	24/100
Optional Liting Motor (DC)	kw	0.8	0.8
Optional Charger	V/A	24/15	24/15
